Scorpion Tribunus 12-130A ESC SBEC
Scorpion Tribunus 12-130A ESC SBEC
Regular price
$319.99
Regular price
Sale price
$319.99
Unit price
per
Couldn't load pickup availability
Airplane and Heli mode,
Stored and unstored Governor, external governor.
Data Logging, Data output port for external data logging device, such as Mikado V control / Vbar combinations. Jeti Telemetry , JLog 3 ( more compatible device will be added gradually like Futaba..etc.)
ESC setup can be set by Mikado V control Radio.
PC connectivity, Android connectivity ( OTG cable needed) , V link II Cable(optional) plus Diode adaptor(included) cable needed.
Supported HvLi battery 12S total 52V.
Size: 75.3 x 44.3 x 25.7 mm
Weight: 195 Grams.
Specifications
| Max Continuous Current | 130 Amps |
| Peak Current | 200 Amps |
| Operating Voltage Range | 14-52 Volts |
| BEC Output voltage: | 5.1V to 8.3V adjustable. |
| Max Continuous BEC Output | 10 Amps @ 8.3 V |
| Peak BEC Output | 20 Amps/1s @ 8.3 V |
| On Resistance | 0.7 mOhms *2 |
| Size | 75.3 x 44.3 x 25.7 mm (2.96 x 1.74 x 1.01 in) |
| Weight (Without Connectors) | 195 g (6.87 oz) |
| Drive frequency | 8kHz - 32kHz |
Included in the Box
Diode adaptor cable *1
Connection cable *2
